2023 Chevy Traverse | Mid-Size 3-Row SUV

18 – FWD
17 – AWD

Highway

27 – FWD
25 – AWD

3.6L DOHC V-6 with direct injection and automatic stop/start

Bore & stroke (in. / mm):

3.70 x 3.37 / 94 x 85.6

Block material:

Cast aluminum w/ cast-in-place iron bore liners

Cylinder head material:

Cast aluminum

Valvetrain:

Dual-overhead camshafts, four valves per cylinder, continuous variable valve timing

Fuel delivery:

Direct, high-pressure fuel injection with electronic throttle control

Horsepower (hp / kW @ rpm):

310 / 231 @ 6800

Torque (lb.-ft. / Nm @ rpm):

266 / 360 @ 2800

Hydra-Matic 9T65 nine-speed automatic

Gear Ratios (:1)

     First

4.69

     Second

3.31

     Third

3.01

     Fourth

2.44

     Fifth

1.92

     Sixth

1.44

     Seventh

1.00

     Eighth

0.75

     Ninth

0.62

     Reverse

2.96

Final Drive Ratio:

3.49

MacPherson strut independent with hydraulic control arm ride bushing and hollow stabilizer bar

Rear Suspension:

Five-link independent with auxiliary spring aids and hollow stabilizer bar

Steering Type:

Electric variable-effort power steering with Active Return Assist

Turning Circle (ft. / m):

39.0 / 11.9

Brake Type:

Four-wheel-disc, variable brake system with power assist; Duralife brake rotors and low-drag brake calipers

Brake Rotor Diameter            (in. / mm):

12.64 / 321 (front)
12.40 / 315 (rear)

Wheel Size:

18-in. aluminum (standard LS, LT Cloth and LT Leather)
20-in. aluminum (standard RS, Premier and High Country; available LT Leather)

Tire Size:

P225/65R18 all-season
P255/55R20 all-season

120.9 / 3072

Overall Length (in. / mm):

205.9 / 5230

Overall Width (in. / mm):

78.6 / 1996 (without mirrors)

Overall Height (in. / mm):

70.7 / 1796

Track (in. / mm):

67.3 / 1709 (front)
67 / 1703 (rear)

42.8 / 1087 (front – without sunroof)
41.5 / 1053 (front – with sunroof)
40.0 / 1017 (second row – without sunroof)
39.0 / 991 (second row – with sunroof)
38.2 / 971 (third row – with or without sunroof)

Legroom (in. / mm):

41.0 / 1042 (front)
44.5 / 1131 (front – max)
38.4 / 976 (effective second row)
33.5 / 850 (effective third row)

Shoulder Room (in. / mm):

61.9 / 1573 (front)
62.2 / 1579 (second row)
57.5 / 1461 (third row)

Hip Room (in. / mm):

58.1 / 1476 (front)
56.9 / 1446 (second row)
48.5 / 1232 (third row)

EPA Pass. Volume (cu. ft. / L):

157.1 / 4448

TBD

Max Cargo Volume¹ (cu. ft. / L):

23 / 652 (behind second row)
57.8 /1636 (behind second row; third row folded)
98.2 / 2781 (second and third rows folded)

Trailering Capacity² (lb. / kg):

5000 / 2268 (with avail. trailering pkg.)

Safety Package¹ is available on LS. Content includes Rear Park Assist, Lane Change Alert with Side Blind Zone Alert and Rear Cross Traffic Alert. Content is standard on LT Cloth, LT Leather, RS, Premier and High Country

Rear Pedestrian Alert¹ is standard on RS, Premier and High Country, and available on LT Cloth and LT Leather

Safety Alert Seat¹ is standard on Premier and High Country

Adaptive Cruise Control¹ is standard on RS, Premier and High Country, and available on LT Leather

Enhanced Automatic Emergency Braking¹ is standard on RS, Premier and High Country, and available on LT Leather

Rear Vision Camera¹ is standard on LS, LT Cloth and LT Leather

HD Surround Vision2 and Rear Camera Mirror¹ are standard on RS, Premier and High Country and available on LT Cloth and LT Leather

Airbags²: Frontal and seat-mounted side-impact for driver and front passenger; driver inboard seat-mounted side-impact; and roof-rail mounted head-curtain for outboard seating positions. Includes Passenger Sensing System

Buckle to Drive is standard

Standard Tire Pressure Monitor System; tire pressure monitor includes tire fill alert (excludes spare tire, if equipped)
